The MRCOOL® DIY® 36K BTU 5th Generation Ductless Mini Split Heat Pump System provides powerful year-round heating and cooling for spaces up to approximately 1,500 square feet. With 36,000 BTU capacity, 18 SEER2 efficiency, and 208/230V operation, this single-zone system is designed to deliver dependable comfort with convenient DIY installation.
Installation is simplified with the included 25-foot pre-charged DIY® QuickConnect® line set containing R-454B refrigerant, eliminating the need for vacuuming. The included DIYPRO® cable replaces traditional electrical conduit and provides additional protection against outdoor elements and wildlife, helping make installation faster and more straightforward.
Multiple control options make everyday operation convenient, including the wireless remote, SmartHVAC app, Amazon Alexa, and Google Assistant. Follow Me® technology helps maintain consistent comfort by sensing the temperature around the remote, while Dry Mode helps reduce excess humidity. The Gold Fin® condenser coating provides enhanced corrosion resistance for reliable performance, including in coastal environments.
What's Included
-
MRCOOL DIY 36K BTU 5th Gen Ductless Mini Split Condenser - 230V, DIY-36-HP-C-230D25-O
Pre-charged condenser, mounting feet, and installation manual -
MRCOOL DIY 5th Generation 36K BTU Wall Mount Air Handler - 230V, DIY-36-HP-WMAH-230D25-O
Air handler, mounting plate and wall template, remote with batteries, washable filter, and drain hose -
MRCOOL Lineset for DIY 5th Gen Mini Split Systems - R-454B
25 ft pre-charged QuickConnect® line set, communication wire, wall sleeve, drain line extension, and UV-resistant wrap
Specifications:
|
BRAND NAME |
MRCOOL |
|
SERIES |
DIY 5th gen Single-Zone Mini-splits |
|
CONDENSER MODEL |
DIY-36-HP-C-230D25-O |
|
AIR HANDLER MODEL |
DIY-36-HP-WMAH-230D25-O |
|
CONDENSER GTIN |
840255586986 |
|
AIR HANDLER GTIN |
840255587068 |
|
SEER2 |
18 |
|
EER2 |
8.5 |
|
HSPF2-4 |
8.5 |
|
HSPF2-5 |
6.5 |
|
TONNAGE |
3 |
|
COOLING CAPACITY (BTU) |
36,000 |
|
HEATING CAPACITY (BTU) |
36,000 |
|
VOLTAGE (V) |
208/230 |
|
PHASE |
1 |
|
CYCLE |
60 |
|
MAX FUSE BREAKER (A) |
35 |
|
MIN CIRCUIT AMPACITY (A) |
33 |
|
COLOR |
White |
|
ZONE CAPACITY |
1 |
|
REFRIGERANT TYPE |
R-454B |
|
REFRIGERANT VOLUME (OZ) |
109.7 |
|
DECIBEL RATING (DBA) |
60.5 |
|
INVERTER |
DC |
|
LINE SET LENGTH |
25 ft |
|
MAX LINESET LENGTH (FT) |
213.2 |
|
LIQUID LINE SIZE |
3/8 in |
|
SUCTION LINE SIZE |
5/8 in |
|
COMPRESSOR MOTOR TYPE |
Rotary |
|
AUXILIARY HEATER INCLUDED |
No |
|
AUXILIARY HEATER AVAILABLE |
No |
|
FAN ONLY OPTION |
Yes |
|
QUIET MODE |
Yes |
|
AUTO COOL |
Yes |
|
WIFI COMPATIBILITY |
Yes |
|
APP COMPATIBILITY |
Yes |
|
WORKS WITH IOS |
Yes |
|
WORKS WITH ANDROID |
Yes |
|
REMOTE CONTROL INCLUDED |
Yes |
|
UL LISTED |
Yes |
|
ETL LISTED |
Yes |
|
AHRI CERTIFIED |
Yes |
|
MOUNT TYPE |
Wall |
|
MAX COVERAGE AREA |
1,550 sqft |
|
DECIBEL RATING LOW (DBA) |
27.5 |
|
DECIBEL RATING HIGH (DBA) |
55.5 |
|
OSCILLATION |
Yes |
|
FILTER TYPE |
Reusable |
|
BASE PARTS WARRANTY |
5 years |
|
BASE COMPRESSOR WARRANTY |
7 years |
|
NET DEPTH (IN) |
16.14 |
|
NET HEIGHT (IN) |
31.89 |
|
NET WIDTH (IN) |
37.24 |
|
NET WEIGHT (LBS) |
152.12 |
|
GROSS DEPTH (IN) |
19.88 |
|
GROSS HEIGHT (IN) |
37.01 |
|
GROSS WIDTH (IN) |
42.91 |
|
GROSS WEIGHT (LBS) |
183.42 |
|
AIR HANDLER NET DEPTH (IN) |
11.1 |
|
AIR HANDLER NET HEIGHT (IN) |
14.25 |
|
AIR HANDLER NET WIDTH (IN) |
49.57 |
|
AIR HANDLER NET WEIGHT (LBS) |
48.72 |
|
AIR HANDLER GROSS DEPTH (IN) |
18.74 |
|
AIR HANDLER GROSS HEIGHT (IN) |
16.57 |
|
AIR HANDLER GROSS WIDTH (IN) |
53.94 |
|
AIR HANDLER GROSS WEIGHT (LBS) |
67.9 |
