The MRCOOL® DIY® 5th Generation Multi-Zone 18,000 BTU system provides efficient heating and cooling for two separate indoor spaces with a 12,000 BTU + 12,000 BTU configuration. With a 23.9 SEER2 rating, DC inverter technology, and an 18,000 BTU outdoor condenser, this ductless heat pump system is designed to deliver reliable year-round comfort with efficient operation.
Designed for convenient DIY® installation, the system uses MRCOOL® Quick Connect® technology with pre-charged R-454B refrigerant line sets. The two 12,000 BTU wall-mounted air handlers can each provide heating and cooling for spaces of approximately 550 square feet, making this system suitable for multi-room residential applications.
The system includes smartphone app controls, Follow Me® temperature sensing, Gold Fin® condenser protection, low ambient cooling, quiet operation, and compatibility with modern smart-home controls. The condenser is backed by a 5-year parts warranty and 7-year compressor warranty, with extended limited lifetime replacement coverage available through the MRCOOL® Care Program.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 18,000 BTU Mini Split Condenser, DIY-MULTI3-18HP230D-O -
MRCOOL DIY 5th Gen 12,000 BTU Wall Mount Air Handler, DIY-12-HP-WMAH-230D25-O
Specifications:
|
BRAND NAME |
MRCOOL |
|
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
|
MODEL |
DIY-MULTI3-18HP230D-O / DIY-12-HP-WMAH-230D25-O |
|
GTIN |
840255587617 / 840255587037 |
|
UPC |
840255587617 / 840255587037 |
|
EQUIPMENT TYPE |
Multi-Zone Ductless Mini-Split Heat Pump |
|
TONNAGE |
1.5 |
|
COOLING CAPACITY (BTU) |
18,000 |
|
HEATING CAPACITY (BTU) |
18,000 |
|
SEER2 |
23.9 |
|
EER2 |
13 |
|
HSPF2-4 |
10 |
|
HSPF2-5 |
7.8 |
|
VOLTAGE / PHASE / FREQUENCY |
208/230 V / 1 / 60 Hz |
|
MAX FUSE / BREAKER (A) |
20 |
|
MIN CIRCUIT AMPACITY (A) |
16 |
|
COLOR |
White |
|
ZONE CAPACITY |
2 |
|
REFRIGERANT TYPE |
R-454B |
|
REFRIGERANT VOLUME (OZ) |
61.73 |
|
DECIBEL RATING (DBA) |
60 |
|
INVERTER |
DC |
|
LINE SET LENGTH |
25 ft |
|
MAX LINESET LENGTH |
172.2 ft |
|
LIQUID LINE SIZE |
1/4 in |
|
SUCTION LINE SIZE |
3/8 in |
|
COMPRESSOR MOTOR TYPE |
Rotary |
|
AUXILIARY HEATER |
Not Included / Not Available |
|
FAN ONLY OPTION |
Yes |
|
QUIET MODE |
Yes |
|
AUTO COOL |
Yes |
|
WIFI COMPATIBILITY |
Yes |
|
APP COMPATIBILITY |
Yes |
|
WORKS WITH IOS |
Yes |
|
WORKS WITH ANDROID |
Yes |
|
ENERGY STAR CERTIFIED |
Yes |
|
AHRI CERTIFIED |
Yes |
|
REGISTERED WARRANTY |
Extended Limited Lifetime |
|
BASE PARTS WARRANTY |
5 years |
|
BASE COMPRESSOR WARRANTY |
7 years |
|
CONDENSER DIMENSIONS (D X H X W) |
13.46 x 26.50 x 35.04 in |
|
CONDENSER NET WEIGHT |
101.63 lbs |
|
AIR HANDLER MODEL |
DIY-12-HP-WMAH-230D25-O |
|
AIR HANDLER VOLTAGE / PHASE / CYCLE |
208/230 V / 1 / 60 Hz |
|
AIR HANDLER MOUNT TYPE |
Wall |
|
AIR HANDLER MAX COVERAGE AREA |
550 sqft each |
|
AIR HANDLER FILTER TYPE |
Reusable |
|
REMOTE CONTROL INCLUDED |
Yes |
|
AIR HANDLER NET DIMENSIONS (D X H X W) |
7.44 x 11.63 x 31.57 in |
|
AIR HANDLER NET WEIGHT |
24.47 lbs each |
|
AIR HANDLER GROSS DIMENSIONS (D X H X W) |
16.34 x 14.37 x 36.02 in |
|
AIR HANDLER GROSS WEIGHT |
35.05 lbs each |
|
AIR HANDLER WARRANTY |
5-year Parts / 7-year Compressor |
