The MRCOOL® DIY® 5th Generation Multi-Zone 27,000 BTU ductless mini-split system combines a 12,000 BTU and an 18,000 BTU wall-mounted air handler to provide independent comfort across two separate living spaces. With a 23 SEER2 rating and DC inverter technology, the system is designed to deliver efficient heating and cooling throughout the year.
The multi-zone system features a 27,000 BTU condenser capable of supporting multiple indoor units, while this configuration pairs it with 12,000 BTU and 18,000 BTU air handlers covering approximately 550 and 800 square feet respectively. MRCOOL® DIY® Quick Connect® technology uses pre-charged line sets with R-454B refrigerant, simplifying installation without requiring special HVAC tools or training.
Smart HVAC controls allow convenient operation through the MRCOOL® Smart HVAC Controller® and smartphone app, with Google Assistant and Amazon Alexa compatibility. Features such as Follow Me®, low ambient cooling, quiet mode, automatic cooling, reusable filters, Gold Fin® condenser protection, and a sealed R-454B system provide dependable performance and flexible comfort. The system includes a 5-year parts warranty, 7-year compressor warranty, and extended limited lifetime replacement coverage when enrolled in the MRCOOL® Care Program.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 27,000 BTU Mini Split Condenser, DIY-MULTI4-27HP230D-O -
MRCOOL DIY 5th Gen 12,000 BTU Wall Mount Air Handler, DIY-12-HP-WMAH-230D25-O -
MRCOOL DIY 5th Gen 18,000 BTU Wall Mount Air Handler, DIY-18-HP-WMAH-230D25-O
Specifications:
|
BRAND NAME |
MRCOOL |
|
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
|
MODEL |
DIY-MULTI4-27HP230D-O / DIY-12-HP-WMAH-230D25-O / DIY-18-HP-WMAH-230D25-O |
|
SKU |
DIYM227HPW10D24 |
|
EQUIPMENT TYPE |
Multi-Zone Ductless Mini-Split Heat Pump |
|
CONFIGURATION |
2-Zone (12K + 18K) |
|
TONNAGE |
2.25 |
|
COOLING CAPACITY (BTU/H) |
26,000 |
|
HEATING CAPACITY (BTU/H) |
26,000 |
|
SEER2 |
23 |
|
EER2 |
12 |
|
HSPF2-4 |
9.5 |
|
HSPF2-5 |
7 |
|
VOLTAGE / PHASE / FREQUENCY |
208/230 V / 1 / 60 Hz |
|
MAX FUSE / BREAKER (A) |
25 |
|
MIN CIRCUIT AMPACITY (A) |
23 |
|
COLOR |
White |
|
ZONE CAPACITY |
4 |
|
REFRIGERANT TYPE |
R-454B |
|
REFRIGERANT VOLUME (OZ) |
84.66 |
|
DECIBEL RATING (DBA) |
61 |
|
INVERTER |
DC |
|
LINE SET LENGTH (FT) |
25 |
|
MAX LINE SET LENGTH (FT) |
221.4 |
|
LIQUID LINE SIZE |
1/4 in |
|
SUCTION LINE SIZE |
3/8 in |
|
COMPRESSOR MOTOR TYPE |
Rotary |
|
AUXILIARY HEATER |
No |
|
FEATURES |
Fan Only, Quiet Mode, Auto Cool, WiFi, Smartphone App, Follow Me, Low Ambient Cooling |
|
SMART CONTROLS |
Google Assistant / Amazon Alexa |
|
CERTIFICATIONS |
UL / ETL / ENERGY STAR / AHRI |
|
BASE PARTS WARRANTY |
5 years |
|
BASE COMPRESSOR WARRANTY |
7 years |
|
REGISTERED WARRANTY |
Extended Limited Lifetime* |
|
CONDENSER DIMENSIONS (D X H X W) |
16.14 x 31.89 x 37.24 in |
|
CONDENSER NET / GROSS WEIGHT |
140.21 / 151.02 lb |
|
AIR HANDLER MODELS |
DIY-12-HP-WMAH-230D25-O / DIY-18-HP-WMAH-230D25-O |
|
AIR HANDLER CAPACITIES |
12,000 BTU / 18,000 BTU |
|
MAX COVERAGE AREA |
550 sqft / 800 sqft |
|
AIR HANDLER MOUNT TYPE |
Wall |
|
AIR HANDLER VOLTAGE / PHASE / FREQUENCY |
208/230 V / 1 / 60 Hz |
|
AIR HANDLER COLOR |
White |
|
AIR HANDLER FILTER TYPE |
Reusable |
|
AIR HANDLER FEATURES |
Oscillation, Fan Only, Quiet Mode, Auto Cool, WiFi, App, iOS, Android, Remote Control |
|
AIR HANDLER CERTIFICATIONS |
UL / ETL / AHRI |
|
AIR HANDLER WARRANTY |
5-year Parts / 7-year Compressor |
|
AIR HANDLER DIMENSIONS (D X H X W) |
7.44 x 11.63 x 31.57 in / 8.9 x 13.19 x 42.52 in |
|
AIR HANDLER NET / GROSS WEIGHT |
24.47 / 35.05 lb / 35.49 / 49.6 lb |
