The MRCOOL® DIY® 5th Gen Multi-Zone 48,000 BTU Ductless Mini-Split Heat Pump System is designed to provide efficient heating and cooling for two separate living spaces. This 4-ton system combines a 12,000 BTU wall-mounted air handler with a 36,000 BTU wall-mounted air handler and a powerful multi-zone inverter condenser, delivering flexible comfort with up to 21.8 SEER2 efficiency.
Built around MRCOOL® DIY® technology, the system uses pre-charged Quick Connect® line sets with R-454B refrigerant to simplify installation without the traditional evacuation and refrigerant-charging process for qualifying installations. The system also supports SmartHVAC app control, Follow Me® functionality, quiet operation, and multiple operating modes for convenient year-round temperature management.
The 12,000 BTU air handler is designed for spaces up to approximately 550 square feet, while the 36,000 BTU air handler can serve spaces up to approximately 1,550 square feet. With 43,000 BTU cooling capacity, 48,000 BTU heating capacity, ENERGY STAR® and AHRI certifications, a 5-year parts warranty, and a 7-year compressor warranty, this multi-zone system provides a versatile solution for larger residential applications.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 48,000 BTU Mini Split Condenser, DIY-MULTI6-48HP230D-O -
MRCOOL DIY 5th Gen 12,000 BTU Wall Mount Air Handler, DIY-12-HP-WMAH-230D25-O -
MRCOOL DIY 5th Gen 36,000 BTU Wall Mount Air Handler, DIY-36-HP-WMAH-230D25-O
Specifications:
BRAND NAME |
MRCOOL |
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
MODEL |
DIYM248HPW04D / DIY-12-HP-WMAH-230D25-O / DIY-36-HP-WMAH-230D25-O |
EQUIPMENT TYPE |
Multi-Zone Inverter Condenser / Wall-Mounted Air Handlers |
TOTAL SYSTEM CAPACITY |
48,000 BTU |
AIR HANDLER CONFIGURATION |
12,000 BTU + 36,000 BTU |
TONNAGE |
4 |
COOLING CAPACITY (BTU) |
43,000 |
HEATING CAPACITY (BTU) |
48,000 |
SEER2 |
21.8 |
EER2 |
12 |
HSPF2-4 |
10 |
HSPF2-5 |
7.8 |
VOLTAGE / PHASE / FREQUENCY |
208/230 V / 1 / 60 Hz |
MIN CIRCUIT AMPACITY (A) |
40 |
MAX FUSE / BREAKER (A) |
45 |
REFRIGERANT |
R-454B |
REFRIGERANT VOLUME (OZ) |
148.15 |
COMPRESSOR MOTOR TYPE |
Rotary |
INVERTER |
DC |
ZONE CAPACITY |
6 |
MAX LINESET LENGTH (FT) |
221.4 |
LINE SET LENGTH |
25 ft |
LIQUID LINE SIZE |
1/4 in |
SUCTION LINE SIZE |
3/8 in x 4 / 1/2 in x 2 |
DECIBEL RATING (DBA) |
64 |
COLOR |
White |
AIR HANDLER MOUNT TYPE |
Wall |
AIR HANDLER COVERAGE |
550 sqft / 1,550 sqft |
AIR HANDLER VOLTAGE |
208/230 V |
AIR HANDLER FILTER |
Reusable |
AUXILIARY HEATER |
Not included / Not available |
FAN ONLY |
Yes |
QUIET MODE |
Yes |
AUTO COOL |
Yes |
WIFI / APP COMPATIBILITY |
Yes |
IOS / ANDROID COMPATIBILITY |
Yes / Yes |
REMOTE CONTROL INCLUDED |
Yes |
UL / ETL / AHRI CERTIFIED |
Yes / Yes / Yes |
ENERGY STAR CERTIFIED |
Yes |
BASE PARTS WARRANTY |
5 years |
BASE COMPRESSOR WARRANTY |
7 years |
REGISTERED WARRANTY |
Extended Limited Lifetime |
NET DIMENSIONS (W X D X H) |
37.48 x 16.34 x 52.48 in / 31.57 x 7.44 x 11.63 in / 49.57 x 11.1 x 14.25 in |
NET WEIGHT |
223.77 lb / 24.47 lb / 48.72 lb |
GROSS DIMENSIONS (W X D X H) |
43.11 x 19.49 x 58.27 in / 36.02 x 16.34 x 14.37 in / 53.94 x 18.74 x 16.57 in |
GROSS WEIGHT |
256.39 lb / 35.05 lb / 67.9 lb |
