The MRCOOL® DIY® 5th Gen Multi-Zone 48,000 BTU Ductless Mini-Split System provides powerful heating and cooling for two large spaces with a 24,000 BTU and 36,000 BTU wall-mounted air handler configuration. With a 4-ton capacity and up to 21.8 SEER2 efficiency, this system is designed to deliver efficient year-round comfort while allowing each zone to be controlled independently.
The system combines a high-capacity multi-zone condenser with two wall-mounted air handlers designed for convenient DIY installation. MRCOOL® pre-charged Quick Connect® line sets use R-454B refrigerant and are designed to simplify installation by eliminating the traditional evacuation and charging process when compatible components are used. The 24K air handler provides coverage for spaces up to approximately 1,050 square feet, while the 36K air handler can cover up to approximately 1,550 square feet.
Built with DC inverter technology, Gold Fin® condenser protection, Follow Me® functionality, low ambient cooling, and smartphone app controls, the system provides flexible comfort and convenient operation. It supports Google Assistant and Amazon Alexa integration and includes ENERGY STAR® and AHRI certification, a 5-year parts warranty, and a 7-year compressor warranty, with extended limited lifetime coverage available through the MRCOOL® Care Program.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 48,000 BTU Mini Split Condenser, DIY-MULTI6-48HP230D-O -
MRCOOL DIY 5th Gen 24,000 BTU Wall Mount Air Handler, DIY-24-HP-WMAH-230D25-O -
MRCOOL DIY 5th Gen 36,000 BTU Wall Mount Air Handler, DIY-36-HP-WMAH-230D25-O
Specifications:
BRAND NAME |
MRCOOL |
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
MODEL |
DIY-MULTI6-48HP230D-O / DIY-24-HP-WMAH-230D25-O / DIY-36-HP-WMAH-230D25-O |
EQUIPMENT TYPE |
Ductless Mini-Split Air Conditioner and Heat Pump |
ZONE CONFIGURATION |
2-Zone |
SYSTEM CAPACITY |
48,000 BTU |
INDOOR UNIT CONFIGURATION |
24,000 BTU + 36,000 BTU |
TONNAGE |
4 |
SEER2 |
21.8 |
EER2 |
12 |
HSPF2-4 |
10 |
HSPF2-5 |
7.8 |
COOLING CAPACITY |
43,000 BTU |
HEATING CAPACITY |
48,000 BTU |
VOLTAGE / PHASE / FREQUENCY |
208/230 V / 1 / 60 Hz |
MIN CIRCUIT AMPACITY (A) |
40 |
MAX FUSE / BREAKER (A) |
45 |
REFRIGERANT |
R-454B |
REFRIGERANT VOLUME (OZ) |
148.15 |
COMPRESSOR MOTOR TYPE |
Rotary |
INVERTER |
DC |
ZONE CAPACITY |
Up to 6 zones |
CONDENSER SOUND LEVEL (DBA) |
64 |
24K AIR HANDLER COVERAGE |
1,050 sq. ft. |
36K AIR HANDLER COVERAGE |
1,550 sq. ft. |
24K AIR HANDLER SOUND LEVEL (DBA) |
20 - 54 |
36K AIR HANDLER SOUND LEVEL (DBA) |
27.5 - 55.5 |
LINE SET LENGTH |
25 ft |
MAX LINE SET LENGTH |
221.4 ft |
LIQUID LINE SIZE |
1/4 in condenser / 3/8 in air handlers |
SUCTION LINE SIZE |
3/8 in x4 and 1/2 in x2 condenser / 5/8 in air handlers |
AIR HANDLER MOUNT TYPE |
Wall Mount |
AIR HANDLER FAN SPEEDS |
5 |
AIR HANDLER OSCILLATION |
Yes |
FILTER TYPE |
Reusable |
REMOTE CONTROL |
Included |
WIFI / APP COMPATIBILITY |
Yes |
SMART HOME COMPATIBILITY |
Google Assistant and Amazon Alexa |
FAN ONLY OPTION |
Yes |
QUIET MODE |
Yes |
AUTO COOL |
Yes |
LOW AMBIENT COOLING |
Yes |
UL / ETL LISTED |
Yes |
ENERGY STAR CERTIFIED |
Yes |
AHRI CERTIFIED |
Yes |
BASE PARTS WARRANTY |
5 years |
BASE COMPRESSOR WARRANTY |
7 years |
EXTENDED WARRANTY |
Limited Lifetime with MRCOOL Care Program |
CONDENSER DIMENSIONS (W X D X H) |
37.48 x 16.34 x 52.48 in |
24K AIR HANDLER DIMENSIONS (W X D X H) |
42.52 x 8.90 x 13.19 in |
36K AIR HANDLER DIMENSIONS (W X D X H) |
49.57 x 11.10 x 14.25 in |
CONDENSER NET WEIGHT |
223.77 lb |
24K AIR HANDLER NET WEIGHT |
35.93 lb |
36K AIR HANDLER NET WEIGHT |
48.72 lb |
