The MRCOOL® DIY® 5th Gen Multi-Zone 55,000 BTU Ductless Mini-Split System delivers powerful heating and cooling across two separate zones with a 24,000 BTU and 36,000 BTU indoor unit configuration. With a 22 SEER2 rating and advanced DC inverter technology, this system provides efficient performance and responsive comfort for larger residential spaces.
Designed with DIY installation in mind, the system uses MRCOOL® Quick Connect® pre-charged line set technology to simplify installation and reduce the need for traditional refrigerant evacuation and charging. The 55,000 BTU multi-zone condenser works with the included 24K and 36K wall-mounted air handlers, allowing each zone to receive targeted heating and cooling.
Convenient features include R-454B refrigerant, Gold Fin® condenser protection, Follow Me® temperature sensing, low ambient cooling, quiet operation, and smartphone control through the Smart HVAC app. Wi-Fi connectivity with Amazon Alexa and Google Assistant compatibility adds flexible control, while ENERGY STAR® and AHRI certifications support efficient and dependable operation.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 55,000 BTU Mini Split Condenser, DIY-MULTI6-55HP230D-O -
MRCOOL DIY 5th Gen 24,000 BTU Wall Mount Air Handler, DIY-24-HP-WMAH-230D25-O -
MRCOOL DIY 5th Gen 36,000 BTU Wall Mount Air Handler, DIY-36-HP-WMAH-230D25-O
Specifications:
BRAND NAME |
MRCOOL |
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
MODEL |
DIY-MULTI6-55HP230D-O / DIY-24-HP-WMAH-230D25-O / DIY-36-HP-WMAH-230D25-O |
EQUIPMENT TYPE |
Multi-Zone DC Inverter Mini-Split Condenser / Wall-Mounted Air Handlers |
SYSTEM CAPACITY |
55,000 BTU |
INDOOR CONFIGURATION |
24,000 BTU + 36,000 BTU |
TONNAGE |
4.6 |
SEER2 / EER2 |
22 / 12 |
HSPF2-4 / HSPF2-5 |
10.6 / 8.5 |
COOLING / HEATING CAPACITY |
47,000 / 55,000 BTU |
VOLTAGE / PHASE / FREQUENCY |
208/230 V / 1 / 60 Hz |
MIN CIRCUIT AMPACITY / MAX FUSE BREAKER |
43 A / 45 A |
REFRIGERANT |
R-454B |
REFRIGERANT VOLUME |
151.68 oz |
COMPRESSOR MOTOR / INVERTER |
Rotary / DC |
ZONE CAPACITY |
6 zones |
OUTDOOR SOUND LEVEL |
64 dBA |
LINE SET LENGTH / MAX LENGTH |
25 ft / 221.4 ft |
LIQUID / SUCTION LINE SIZE |
1/4 in / (3/8 x 4) + (1/2 x 2) |
AIR HANDLER CAPACITY |
24,000 BTU + 36,000 BTU |
AIR HANDLER TONNAGE |
2 ton + 3 ton |
AIR HANDLER MAX COVERAGE AREA |
1,050 sqft + 1,550 sqft |
AIR HANDLER SOUND LEVEL |
20 - 54 dBA / 27.5 - 55.5 dBA |
AIR HANDLER LIQUID / SUCTION LINE SIZE |
3/8 in / 5/8 in |
AIR HANDLER MOUNT TYPE / FILTER |
Wall / Reusable |
AIR HANDLER NUMBER OF SPEEDS |
5 each |
AIR HANDLER FEATURES |
Oscillation / Fan Only / Quiet Mode / Auto Cool |
SMART FEATURES |
Wi-Fi / App / iOS / Android / Alexa / Google Assistant |
CERTIFICATIONS |
UL / ETL / ENERGY STAR / AHRI |
WARRANTY |
5-Year Parts / 7-Year Compressor / Extended Limited Lifetime* |
CONDENSER NET DIMENSIONS (W X D X H) |
37.48 x 16.34 x 52.48 in |
AIR HANDLER NET DIMENSIONS (W X D X H) |
42.52 x 8.9 x 13.19 in / 49.57 x 11.1 x 14.25 in |
NET WEIGHT |
245.81 lb / 35.93 lb / 48.72 lb |
