The MRCOOL® DIY® 5th Gen Multi-Zone 18,000 BTU Ductless Mini Split is designed to provide independent heating and cooling across three separate rooms. With three 6,000 BTU wall-mounted air handlers, this system delivers targeted comfort while maintaining efficient multi-zone operation.
Each 6,000 BTU air handler can condition approximately 200 square feet, making this configuration well suited for bedrooms, offices, smaller living areas, additions, or other compact spaces. The 18,000 BTU outdoor condenser supplies all three indoor units through a single multi-zone system.
With a 23.9 SEER2 rating, DC inverter technology, R-454B refrigerant, smartphone app controls, and MRCOOL's pre-charged Quick Connect® line set technology, the system combines energy-efficient performance with a simplified DIY installation approach.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 18,000 BTU Mini Split Condenser, DIY-MULTI3-18HP230D-O -
MRCOOL DIY 5th Gen 6,000 BTU Wall Mount Air Handler, DIY-06-HP-WMAH-230D25-O -
MRCOOL DIY 5th Gen R-454B
Specifications:
|
BRAND NAME |
MRCOOL |
|
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
|
EQUIPMENT TYPE |
Ductless Mini Split Heat Pump |
|
ZONE CONFIGURATION |
3-Zone |
|
CONDENSER CAPACITY |
18,000 BTU |
|
SEER2 |
23.9 |
|
COOLING CAPACITY |
18,000 BTU |
|
HEATING CAPACITY |
18,000 BTU |
|
AIR HANDLER CONFIGURATION |
6,000 BTU + 6,000 BTU + 6,000 BTU |
|
AIR HANDLER COVERAGE |
Up to 200 sq. ft. each |
|
TOTAL COVERAGE |
Up to 750 sq. ft. |
|
VOLTAGE |
208/230V |
|
PHASE |
1 |
|
CYCLE |
60 Hz |
|
REFRIGERANT |
R-454B |
|
INVERTER |
DC Inverter |
|
LINE SET |
Pre-Charged Quick Connect® |
|
MAX LINE SET LENGTH |
172.2 ft. |
|
LIQUID LINE SIZE |
1/4 in. |
|
SUCTION LINE SIZE |
3/8 in. |
|
MAX FUSE BREAKER |
20A |
|
MIN CIRCUIT AMPACITY |
16A |
|
CONDENSER NOISE |
60 dBA |
|
CONDENSER MODEL |
DIY-MULTI3-18HP230D-O |
|
AIR HANDLER MODEL |
DIY-06-HP-WMAH-230D25-O |
|
AIR HANDLER MOUNT TYPE |
Wall Mount |
|
AIR HANDLER FILTER |
Reusable |
|
WI-FI COMPATIBILITY |
Yes |
|
APP COMPATIBILITY |
Yes |
|
CERTIFICATIONS |
UL, ETL, ENERGY STAR®, AHRI |
|
BASE PARTS WARRANTY |
5 Years |
|
BASE COMPRESSOR WARRANTY |
7 Years |
|
SKU |
DIYM318HPW00D |
|
GTIN |
840255587617 |
|
UPC |
840255587617 |
