The MRCOOL® DIY® 5th Gen Multi-Zone 27,000 BTU Ductless Mini Split provides independent heating and cooling for three separate areas with two 6,000 BTU wall-mounted air handlers and one 24,000 BTU air handler. The multi-zone configuration allows each space to receive targeted comfort from a single outdoor condenser.
The two 6,000 BTU air handlers are designed for spaces up to approximately 200 square feet each, while the 24,000 BTU air handler can condition up to approximately 1,050 square feet. This combination is suitable for bedrooms, offices, living areas, additions, and larger spaces requiring dedicated temperature control.
With a 23 SEER2 rating, DC inverter technology, R-454B refrigerant, Smart HVAC app compatibility, Follow Me® functionality, and pre-charged Quick Connect® line sets, this system combines energy-efficient performance with a simplified DIY installation approach.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 27,000 BTU Mini Split Condenser, DIY-MULTI4-27HP230D-O -
MRCOOL DIY 5th Gen 6,000 BTU Wall Mount Air Handler, DIY-06-HP-WMAH-230D25-O — Quantity: 2 -
MRCOOL DIY 5th Gen 24,000 BTU Wall Mount Air Handler, DIY-24-HP-WMAH-230D25-O — Quantity: 1
-
MRCOOL DIY 5th Gen R-454B Quick Connect Line Set — Choose line set length for each air handler
Specifications:
BRAND NAME |
MRCOOL |
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
EQUIPMENT TYPE |
Ductless Mini Split Heat Pump |
ZONE CONFIGURATION |
3-Zone |
CONDENSER CAPACITY |
27,000 BTU |
SEER2 |
23 |
EER2 |
12 |
HSPF2-4 |
9.5 |
HSPF2-5 |
7 |
COOLING CAPACITY |
26,000 BTU |
HEATING CAPACITY |
26,000 BTU |
TONNAGE |
2.25 Tons |
AIR HANDLER CONFIGURATION |
6,000 BTU + 6,000 BTU + 24,000 BTU |
AIR HANDLER COVERAGE |
6K: up to 200 sq. ft. each; 24K: up to 1,050 sq. ft. |
VOLTAGE |
208/230V |
PHASE |
1 |
CYCLE |
60 Hz |
REFRIGERANT TYPE |
R-454B |
REFRIGERANT VOLUME |
84.66 oz. |
INVERTER |
DC Inverter |
LINE SET |
Pre-Charged Quick Connect® |
MAX LINE SET LENGTH |
221.4 ft. |
LIQUID LINE SIZE |
1/4 in. |
SUCTION LINE SIZE |
3/8 in. |
MAX FUSE BREAKER |
25A |
MIN CIRCUIT AMPACITY |
23A |
CONDENSER NOISE |
61 dBA |
CONDENSER MODEL |
DIY-MULTI4-27HP230D-O |
AIR HANDLER MODEL |
DIY-06-HP-WMAH-230D25-O × 2; DIY-24-HP-WMAH-230D25-O × 1 |
AIR HANDLER MOUNT TYPE |
Wall Mount |
AIR HANDLER FILTER |
Reusable |
WI-FI COMPATIBILITY |
Yes |
APP COMPATIBILITY |
Yes |
IOS COMPATIBILITY |
Yes |
ANDROID COMPATIBILITY |
Yes |
FAN ONLY OPTION |
Yes |
QUIET MODE |
Yes |
AUTO COOL |
Yes |
FOLLOW ME® FEATURE |
Yes |
CERTIFICATIONS |
UL, ETL, ENERGY STAR®, AHRI |
BASE PARTS WARRANTY |
5 Years |
BASE COMPRESSOR WARRANTY |
7 Years |
SKU |
DIYM327HPW07D124 |
GTIN |
840255587457 |
UPC |
840255587457 |
