The MRCOOL® DIY® 5th Gen Multi-Zone 27,000 BTU Ductless Mini Split provides efficient heating and cooling for three separate rooms with two 9,000 BTU wall-mounted air handlers and one 12,000 BTU air handler. This configuration allows each zone to maintain its own comfort level while operating from a single outdoor condenser.
The two 9,000 BTU air handlers are designed for spaces up to approximately 400 square feet each, while the 12,000 BTU air handler can cover up to approximately 550 square feet. Together, the three indoor units create a flexible multi-zone solution for bedrooms, offices, living spaces, additions, and other areas requiring independent temperature control.
Featuring a 23 SEER2 rating, DC inverter technology, R-454B refrigerant, smartphone controls, Follow Me® functionality, and pre-charged Quick Connect® line sets, this system combines energy-efficient operation with the simplified installation approach of the MRCOOL DIY® series.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 27,000 BTU Mini Split Condenser, DIY-MULTI4-27HP230D-O — Quantity: 1 -
MRCOOL DIY 5th Gen 9,000 BTU Wall Mount Air Handler, DIY-09-HP-WMAH-230D25-O — Quantity: 2 -
MRCOOL DIY 5th Gen 12,000 BTU Wall Mount Air Handler, DIY-12-HP-WMAH-230D25-O — Quantity: 1
-
MRCOOL DIY 5th Gen R-454B Quick Connect Line Sets — Choose the required line set length for each air handler
Specifications:
BRAND NAME |
MRCOOL |
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
EQUIPMENT TYPE |
Ductless Mini Split Heat Pump |
ZONE CONFIGURATION |
3-Zone |
CONDENSER CAPACITY |
27,000 BTU |
SEER2 |
23 |
EER2 |
12 |
HSPF2-4 |
9.5 |
HSPF2-5 |
7 |
COOLING CAPACITY |
26,000 BTU |
HEATING CAPACITY |
26,000 BTU |
TONNAGE |
2.25 Tons |
AIR HANDLER CONFIGURATION |
9,000 BTU + 9,000 BTU + 12,000 BTU |
AIR HANDLER COVERAGE |
9,000 BTU: Up to 400 sq. ft. each; 12,000 BTU: Up to 550 sq. ft. |
TOTAL COVERAGE |
Up to 1,350 sq. ft. |
VOLTAGE |
208/230V |
PHASE |
1 |
CYCLE |
60 Hz |
REFRIGERANT |
R-454B |
INVERTER |
DC Inverter |
LINE SET |
Pre-Charged Quick Connect® |
MAX LINE SET LENGTH |
221.4 ft. |
LIQUID LINE SIZE |
1/4 in. |
SUCTION LINE SIZE |
3/8 in. |
MAX FUSE BREAKER |
25A |
MIN CIRCUIT AMPACITY |
23A |
CONDENSER NOISE |
61 dBA |
CONDENSER MODEL |
DIY-MULTI4-27HP230D-O |
AIR HANDLER MODEL |
DIY-09-HP-WMAH-230D25-O × 2; DIY-12-HP-WMAH-230D25-O × 1 |
AIR HANDLER MOUNT TYPE |
Wall Mount |
AIR HANDLER FILTER |
Reusable |
WI-FI COMPATIBILITY |
Yes |
APP COMPATIBILITY |
Yes |
IOS COMPATIBILITY |
Yes |
ANDROID COMPATIBILITY |
Yes |
FAN ONLY OPTION |
Yes |
QUIET MODE |
Yes |
AUTO COOL |
Yes |
FOLLOW ME® FEATURE |
Yes |
LOW AMBIENT COOLING |
Yes |
CERTIFICATIONS |
UL, ETL, ENERGY STAR®, AHRI |
BASE PARTS WARRANTY |
5 Years |
BASE COMPRESSOR WARRANTY |
7 Years |
SKU |
DIYM327HPW11D124 |
GTIN |
840255587457 |
UPC |
840255587457 |
