The MRCOOL® DIY® 5th Gen Multi-Zone 36,000 BTU Ductless Mini Split is designed to provide independent comfort across three separate zones with one 6,000 BTU and two 9,000 BTU wall-mounted air handlers. This configuration combines efficient multi-zone performance with flexible temperature control for rooms of different sizes.
The 6,000 BTU air handler is designed for spaces of approximately 200 square feet, while each 9,000 BTU air handler can condition approximately 400 square feet. This makes the system well suited for bedrooms, offices, living areas, additions, and other spaces that require individually controlled heating and cooling.
With a 23 SEER2 rating, DC inverter technology, R-454B refrigerant, smartphone app controls, Follow Me® functionality, and pre-charged Quick Connect® line sets, the system provides energy-efficient operation while maintaining the simplified installation approach of the MRCOOL DIY® series.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 36,000 BTU Mini Split Condenser, DIY-MULTI5-36HP230D-O — Quantity: 1 -
MRCOOL DIY 5th Gen 6,000 BTU Wall Mount Air Handler, DIY-06-HP-WMAH-230D25-O — Quantity: 1 -
MRCOOL DIY 5th Gen 9,000 BTU Wall Mount Air Handler, DIY-09-HP-WMAH-230D25-O — Quantity: 2
-
MRCOOL DIY 5th Gen R-454B Quick Connect Line Sets — Choose the required line set length for each air handler
Specifications:
|
BRAND NAME |
MRCOOL |
|
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
|
EQUIPMENT TYPE |
Ductless Mini Split Heat Pump |
|
ZONE CONFIGURATION |
3-Zone |
|
CONDENSER CAPACITY |
36,000 BTU |
|
SEER2 |
23 |
|
COOLING CAPACITY |
34,000 BTU |
|
HEATING CAPACITY |
36,000 BTU |
|
AIR HANDLER CONFIGURATION |
6,000 BTU + 9,000 BTU + 9,000 BTU |
|
AIR HANDLER COVERAGE |
Up to 200 sq. ft. for 6K unit; up to 400 sq. ft. each for 9K units |
|
TOTAL COVERAGE |
Up to 1,000 sq. ft. |
|
VOLTAGE |
208/230V |
|
PHASE |
1 |
|
CYCLE |
60 Hz |
|
REFRIGERANT |
R-454B |
|
INVERTER |
DC Inverter |
|
LINE SET |
Pre-Charged Quick Connect® |
|
MAX LINE SET LENGTH |
221.4 ft. |
|
LIQUID LINE SIZE |
1/4 in. |
|
SUCTION LINE SIZE |
3/8 in. × 4; 1/2 in. × 1 |
|
MAX FUSE BREAKER |
35A |
|
MIN CIRCUIT AMPACITY |
30.5A |
|
CONDENSER NOISE |
64 dBA |
|
CONDENSER MODEL |
DIY-MULTI5-36HP230D-O |
|
AIR HANDLER MODEL |
DIY-06-HP-WMAH-230D25-O × 1; DIY-09-HP-WMAH-230D25-O × 2 |
|
AIR HANDLER MOUNT TYPE |
Wall Mount |
|
AIR HANDLER FILTER |
Reusable |
|
WI-FI COMPATIBILITY |
Yes |
|
APP COMPATIBILITY |
Yes |
|
IOS COMPATIBILITY |
Yes |
|
ANDROID COMPATIBILITY |
Yes |
|
FAN ONLY OPTION |
Yes |
|
QUIET MODE |
Yes |
|
AUTO COOL |
Yes |
|
FOLLOW ME® FEATURE |
Yes |
|
LOW AMBIENT COOLING |
Yes |
|
CERTIFICATIONS |
UL, ETL, ENERGY STAR®, AHRI |
|
BASE PARTS WARRANTY |
5 Years |
|
BASE COMPRESSOR WARRANTY |
7 Years |
|
SKU |
DIYM336HPW03D |
|
GTIN |
840255587464 |
|
UPC |
840255587464 |
