The MRCOOL® DIY® 5th Gen Multi-Zone 36,000 BTU Ductless Mini Split is designed to provide independent heating and cooling across three separate rooms. This configuration combines 9,000 BTU, 12,000 BTU, and 24,000 BTU wall-mounted air handlers for flexible room-by-room comfort.
The three indoor units allow the system to condition different areas according to their individual heating and cooling needs. The 9,000 BTU unit is suited for smaller rooms, while the 12,000 BTU and 24,000 BTU air handlers provide greater capacity for medium and larger living spaces.
With 23 SEER2 efficiency, DC inverter technology, R-454B refrigerant, smartphone app controls, Follow Me® functionality, and a pre-charged Quick Connect® installation design, this system delivers efficient year-round comfort with convenient multi-zone control.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 36,000 BTU Mini Split Condenser, DIY-MULTI5-36HP230D-O -
MRCOOL DIY 5th Gen 9,000 BTU Wall Mount Air Handler, DIY-09-HP-WMAH-230D25-O -
MRCOOL DIY 5th Gen 12,000 BTU Wall Mount Air Handler, DIY-12-HP-WMAH-230D25-O
-
MRCOOL DIY 5th Gen 24,000 BTU Wall Mount Air Handler, DIY-24-HP-WMAH-230D25-O
Specifications:
BRAND NAME |
MRCOOL |
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
EQUIPMENT TYPE |
Ductless Mini Split Heat Pump |
ZONE CONFIGURATION |
3-Zone |
CONDENSER CAPACITY |
36,000 BTU |
SEER2 |
23 |
EER2 |
12 |
HSPF2-4 |
9.9 |
HSPF2-5 |
7.5 |
TONNAGE |
3 Ton |
COOLING CAPACITY |
34,000 BTU |
HEATING CAPACITY |
36,000 BTU |
AIR HANDLER CONFIGURATION |
9,000 BTU + 12,000 BTU + 24,000 BTU |
AIR HANDLER COVERAGE |
9,000 BTU + 12,000 BTU + 24,000 BTU |
TOTAL COVERAGE |
Up to 1,500 sq. ft. |
VOLTAGE |
208/230V |
PHASE |
1 |
CYCLE |
60 Hz |
REFRIGERANT |
R-454B |
INVERTER |
DC Inverter |
LINE SET |
Pre-Charged Quick Connect® |
MAX LINE SET LENGTH |
221.4 ft. |
LIQUID LINE SIZE |
1/4 in. |
SUCTION LINE SIZE |
3/8 in. × 4; 1/2 in. × 1 |
MAX FUSE BREAKER |
35A |
MIN CIRCUIT AMPACITY |
30.5A |
CONDENSER NOISE |
64 dBA |
CONDENSER MODEL |
DIY-MULTI5-36HP230D-O |
9K AIR HANDLER MODEL |
DIY-09-HP-WMAH-230D25-O |
12K AIR HANDLER MODEL |
DIY-12-HP-WMAH-230D25-O |
24K AIR HANDLER MODEL |
DIY-24-HP-WMAH-230D25-O |
AIR HANDLER MOUNT TYPE |
Wall Mount |
AIR HANDLER FILTER |
Reusable |
WIFI COMPATIBILITY |
Yes |
APP COMPATIBILITY |
Yes |
IOS COMPATIBILITY |
Yes |
ANDROID COMPATIBILITY |
Yes |
FAN ONLY OPTION |
Yes |
QUIET MODE |
Yes |
AUTO COOL |
Yes |
FOLLOW ME® FEATURE |
Yes |
LOW AMBIENT COOLING |
Yes |
COMPRESSOR MOTOR TYPE |
Rotary |
AUXILIARY HEATER |
No |
CERTIFICATIONS |
UL, ETL, ENERGY STAR®, AHRI |
BASE PARTS WARRANTY |
5 Years |
BASE COMPRESSOR WARRANTY |
7 Years |
SKU |
DIYM336091224 |
GTIN |
840255587464 |
UPC |
840255587464 |
