The MRCOOL® DIY® 5th Gen Multi-Zone 48,000 BTU Ductless Mini Split is built to deliver efficient heating and cooling across three separate spaces. This configuration pairs 9,000 BTU, 18,000 BTU, and 36,000 BTU wall-mounted air handlers with a powerful 48,000 BTU outdoor condenser.
The three indoor units provide flexible comfort for rooms with different heating and cooling demands. The 9,000 BTU air handler is designed for spaces up to approximately 400 square feet, the 18,000 BTU unit for up to approximately 800 square feet, and the 36,000 BTU unit for areas up to approximately 1,500 square feet.
With 21.8 SEER2 efficiency, DC inverter technology, R-454B refrigerant, SmartHVAC app controls, Follow Me® functionality, and pre-charged Quick Connect® technology, this system provides convenient year-round comfort with a DIY-friendly installation design.
What's Included
-
MRCOOL DIY 5th Gen Multi-Zone 48,000 BTU Mini Split Condenser, DIY-MULTI6-48HP230D-O
Quantity: 1 -
MRCOOL DIY 5th Gen 9,000 BTU Wall Mount Air Handler, DIY-09-HP-WMAH-230D25-O
Quantity: 1 -
MRCOOL DIY 5th Gen 18,000 BTU Wall Mount Air Handler, DIY-18-HP-WMAH-230D25-O
Quantity: 1 -
MRCOOL DIY 5th Gen 36,000 BTU Wall Mount Air Handler, DIY-36-HP-WMAH-230D25-O
Quantity: 1
Specifications:
BRAND NAME |
MRCOOL |
SERIES |
DIY 5th Gen Multi-Zone Mini-Splits |
EQUIPMENT TYPE |
Ductless Mini Split Heat Pump |
ZONE CONFIGURATION |
3-Zone |
CONDENSER CAPACITY |
48,000 BTU |
SEER2 |
21.8 |
EER2 |
12 |
HSPF2-4 |
10 |
HSPF2-5 |
7.8 |
TONNAGE |
4 Ton |
COOLING CAPACITY |
43,000 BTU |
HEATING CAPACITY |
48,000 BTU |
AIR HANDLER CONFIGURATION |
9,000 BTU + 18,000 BTU + 36,000 BTU |
9K AIR HANDLER COVERAGE |
Up to 400 sq. ft. |
18K AIR HANDLER COVERAGE |
Up to 800 sq. ft. |
36K AIR HANDLER COVERAGE |
Up to 1,500 sq. ft. |
VOLTAGE |
208/230V |
PHASE |
1 |
CYCLE |
60 Hz |
REFRIGERANT |
R-454B |
INVERTER |
DC Inverter |
LINE SET |
Pre-Charged Quick Connect® |
MAX LINE SET LENGTH |
221.4 ft. |
LIQUID LINE SIZE |
1/4 in. |
SUCTION LINE SIZE |
3/8 in. × 4; 1/2 in. × 2 |
MAX FUSE BREAKER |
45A |
MIN CIRCUIT AMPACITY |
40A |
CONDENSER NOISE |
64 dBA |
CONDENSER MODEL |
DIY-MULTI6-48HP230D-O |
9K AIR HANDLER MODEL |
DIY-09-HP-WMAH-230D25-O |
18K AIR HANDLER MODEL |
DIY-18-HP-WMAH-230D25-O |
36K AIR HANDLER MODEL |
DIY-36-HP-WMAH-230D25-O |
AIR HANDLER MOUNT TYPE |
Wall Mount |
AIR HANDLER FILTER |
Reusable |
WIFI COMPATIBILITY |
Yes |
APP COMPATIBILITY |
Yes |
IOS COMPATIBILITY |
Yes |
ANDROID COMPATIBILITY |
Yes |
FAN ONLY OPTION |
Yes |
QUIET MODE |
Yes |
AUTO COOL |
Yes |
LOW AMBIENT COOLING |
Yes |
COMPRESSOR MOTOR TYPE |
Rotary |
AUXILIARY HEATER |
No |
CERTIFICATIONS |
UL, ETL, ENERGY STAR®, AHRI |
BASE PARTS WARRANTY |
5 Years |
BASE COMPRESSOR WARRANTY |
7 Years |
SKU |
DIYM348HPW30D124 |
CONDENSER GTIN |
840255587471 |
UPC |
840255587471 |
