The MRCOOL® DIY Easy Pro® 12K Ductless Mini-Split Heat Pump System provides efficient heating and cooling for spaces up to 550 square feet. With a 12,000 BTU capacity, 1-ton configuration, 19.5 SEER2 efficiency, and 115V power supply, this system is designed to deliver dependable year-round comfort with straightforward installation and flexible operation.
The Easy Pro® system includes a wall-mounted air handler and a pre-charged 11.5-foot Fast Connection® line set, allowing the system to be installed without the traditional vacuuming process required by many conventional mini-split systems. Its Follow Me® function helps maintain the desired temperature based on the remote control location, while the washable filter and LED display make everyday operation and maintenance convenient.
The system can be controlled using the included remote, the SmartHVAC app, or compatible Amazon Alexa and Google Assistant devices. With inverter technology, reusable filtration, multiple operating modes, and AHRI certification, the MRCOOL® DIY Easy Pro® 12K system combines convenient installation with dependable heating and cooling performance for residential and light commercial applications.
What's Included
-
MRCOOL DIY Easy Pro 12K 12,000 BTU Single Zone Condenser, EZPRO-12-HP-C-11511DE-O, with 11.5 ft Pre-Charged Line Set -
MRCOOL DIY Easy Pro 12K 12,000 BTU Single Zone Air Handler, EZPRO-12-HP-WMAH-115DE-O
Specifications:
|
BRAND NAME |
MRCOOL |
|
SERIES |
DIY EasyPro |
|
CONDENSER MODEL |
EZPRO-12-HP-C-11511DE-O |
|
AIR HANDLER MODEL |
EZPRO-12-HP-WMAH-115DE-O |
|
EQUIPMENT TYPE |
Ductless Mini-Split Heat Pump |
|
TONNAGE |
1 |
|
COOLING CAPACITY (BTU) |
12,000 |
|
HEATING CAPACITY (BTU) |
12,000 |
|
SEER2 |
19.5 |
|
EER2 |
9 |
|
HSPF2-4 |
9.3 |
|
HSPF2-5 |
7 |
|
VOLTAGE / PHASE / FREQUENCY |
115 V / 1 / 60 Hz |
|
MAX FUSE / BREAKER (A) |
20 |
|
MIN CIRCUIT AMPACITY (A) |
19.5 |
|
REFRIGERANT |
R-454B |
|
REFRIGERANT VOLUME (OZ) |
21.52 |
|
ZONE CAPACITY |
1 |
|
INVERTER |
Yes |
|
LINESET INCLUDED |
Yes |
|
LINE SET LENGTH |
11.5 ft |
|
MAX LINESET LENGTH (FT) |
75 ft |
|
LIQUID LINE SIZE |
1/4 in |
|
SUCTION LINE SIZE |
3/8 in |
|
COMPRESSOR MOTOR TYPE |
Rotary |
|
CONDENSER FAN MOTOR TYPE |
DC |
|
CONDENSER FAN MOTOR RPM |
800/700/600 |
|
METERING DEVICE |
EEV |
|
CFM |
353.2 / 294.3 / 235.4 / 176.6 / 129.5 |
|
MAX COVERAGE AREA |
550 sq. ft. |
|
AIR HANDLER MAX FUSE / BREAKER (A) |
15 |
|
AIR HANDLER MIN CIRCUIT AMPACITY (A) |
3 |
|
AIR HANDLER DECIBEL RATING LOW (DBA) |
17.5 |
|
AIR HANDLER DECIBEL RATING HIGH (DBA) |
44.5 |
|
OUTDOOR DECIBEL RATING (DBA) |
54 |
|
FILTER TYPE |
Reusable |
|
ADJUSTABLE THERMOSTAT |
Yes |
|
FAN ONLY OPTION |
Yes |
|
SLEEP MODE |
Yes |
|
AUTO COOL |
Yes |
|
WIFI COMPATIBILITY |
Yes |
|
APP COMPATIBILITY |
Yes |
|
WORKS WITH IOS |
Yes |
|
WORKS WITH ANDROID |
Yes |
|
REMOTE CONTROL INCLUDED |
Yes |
|
UL LISTED |
Yes |
|
CSA LISTED |
Yes |
|
ETL LISTED |
Yes |
|
ENERGY STAR CERTIFIED |
No |
|
AHRI CERTIFIED |
Yes |
|
BASE PARTS WARRANTY |
3 years |
|
BASE COMPRESSOR WARRANTY |
5 years |
|
CONDENSER NET DIMENSIONS (W X D X H) |
28.35 x 10.63 x 19.49 in |
|
CONDENSER NET WEIGHT |
54.89 lb |
|
AIR HANDLER NET DIMENSIONS (W X D X H) |
31.57 x 7.87 x 11.61 in |
|
AIR HANDLER NET WEIGHT |
24.91 lb |
