The MRCOOL® DIY Easy Pro® 18K Ductless Mini-Split Heat Pump System provides efficient heating and cooling for spaces up to 800 square feet. With an 18,000 BTU heating capacity, 20 SEER2 efficiency, and a 1.5-ton configuration, this 230V system is designed to deliver dependable year-round comfort while maintaining efficient operation.
The Easy Pro® system is designed for straightforward installation and includes an 11.5-foot pre-charged line set with Fast Connection® fittings. Its single-zone design combines a compact outdoor condenser with a wall-mounted air handler, making it a practical solution for bedrooms, offices, garages, and other individual spaces requiring dedicated climate control.
Convenient features include Follow Me® temperature control, an anti-mildew function, washable filters, LED diagnostics, Wi-Fi and app compatibility, and support for Apple and Android devices. The system also works with the included remote control, Amazon Alexa, and Google Assistant, while providing a 3-year parts warranty and 5-year compressor warranty.
What's Included
-
MRCOOL DIY Easy Pro 18K BTU Single Zone Condenser, 230V with 11.5 ft Pre-Charged Line Set -
MRCOOL DIY Easy Pro 18K BTU Single Zone Air Handler, 230V
Specifications:
|
BRAND NAME |
MRCOOL |
|
SERIES |
DIY EasyPro |
|
CONDENSER MODEL |
EZPRO-18-HP-C-23011DE-O |
|
AIR HANDLER MODEL |
EZPRO-18-HP-WMAH-230DE-O |
|
GTIN / UPC |
840255595988 / 840255595490 |
|
EQUIPMENT TYPE |
Ductless Mini-Split Heat Pump |
|
TONNAGE |
1.5 |
|
SEER2 |
20 |
|
EER2 |
9.8 |
|
HSPF2-4 |
8.5 |
|
HSPF2-5 |
6.6 |
|
COOLING CAPACITY (BTU) |
17,000 |
|
HEATING CAPACITY (BTU) |
18,000 |
|
VOLTAGE / PHASE / CYCLE |
208/230 V / 1 / 60 Hz |
|
MAX FUSE / BREAKER (A) |
20 |
|
MIN CIRCUIT AMPACITY (A) |
15 |
|
ZONE CAPACITY |
1 |
|
REFRIGERANT TYPE |
R-454B |
|
REFRIGERANT VOLUME (OZ) |
34.92 |
|
DECIBEL RATING (DBA) |
55 |
|
INVERTER |
Yes |
|
LINE SET INCLUDED |
Yes |
|
LINE SET LENGTH |
11.5 ft |
|
MAX LINE SET LENGTH |
75 ft |
|
LIQUID LINE SIZE |
1/4 in |
|
SUCTION LINE SIZE |
1/2 in |
|
COMPRESSOR MOTOR TYPE |
Rotary |
|
CONDENSER FAN MOTOR TYPE |
DC |
|
METERING DEVICE |
EEV |
|
UL / CSA / ETL LISTED |
Yes / Yes / Yes |
|
ENERGY STAR CERTIFIED |
No |
|
AHRI CERTIFIED |
Yes |
|
BASE WARRANTY |
3 Year Parts, 5 Year Compressor |
|
CONDENSER NET DIMENSIONS (D X H X W) |
11.93 x 21.85 x 30.12 in |
|
CONDENSER NET WEIGHT |
62.61 lb |
|
AIR HANDLER CFM |
470.9 / 400.2 / 329.6 / 270.8 |
|
MAX COVERAGE AREA |
800 sq. ft. |
|
AIR HANDLER DECIBEL RATING LOW (DBA) |
18.5 |
|
AIR HANDLER DECIBEL RATING HIGH (DBA) |
46.5 |
|
OSCILLATION |
Yes |
|
BLOWER MOTOR TYPE |
DC |
|
FILTER TYPE |
Reusable |
|
ADJUSTABLE THERMOSTAT |
Yes |
|
FAN ONLY OPTION |
Yes |
|
SLEEP MODE |
Yes |
|
WIFI COMPATIBILITY |
Yes |
|
APP COMPATIBILITY |
Yes |
|
IOS / ANDROID COMPATIBILITY |
Yes / Yes |
|
REMOTE CONTROL INCLUDED |
Yes |
|
AIR HANDLER WARRANTY |
3 Year Parts |
