The MRCOOL® DIY Easy Pro® 24K BTU Ductless Mini-Split Heat Pump System provides efficient heating and cooling for spaces up to 1,050 square feet. With a 24,000 BTU cooling capacity, 25,000 BTU heating capacity, and 18.9 SEER2 efficiency, this 2-ton, 230V system is designed to deliver dependable year-round comfort with efficient inverter-driven operation.
The Easy Pro® system is designed for straightforward DIY installation and includes an 11.5-foot pre-charged line set with Fast Connection® fittings. Its single-zone configuration combines a wall-mounted air handler with a compact outdoor condenser, making it a practical choice for homes, offices, workshops, and other spaces requiring dedicated heating and cooling.
Convenient features include Follow Me® temperature control, anti-mildew operation, washable reusable filters, LED diagnostics, Wi-Fi and SmartHVAC app compatibility, and support for Apple and Android devices. The system can also be operated with the included wireless remote or compatible Amazon Alexa and Google Assistant devices, backed by a 3-year parts warranty and 5-year compressor warranty.
What's Included
-
MRCOOL DIY 5th Gen EasyPro 24K BTU Single Zone Condenser, 230V with 11.5 ft. DIY Quick Connect Line Set -
MRCOOL DIY 5th Gen EasyPro 24K BTU Single Zone Air Handler, 230V — Quantity: 1
Specifications:
BRAND NAME |
MRCOOL |
SERIES |
DIY EasyPro |
CONDENSER MODEL |
EZPRO-24-HP-C-23011DE-O |
AIR HANDLER MODEL |
EZPRO-24-HP-WMAH-230DE-O |
GTIN / UPC |
840255595995 / 840255596015 |
EQUIPMENT TYPE |
Ductless Mini-Split Heat Pump |
TONNAGE |
2 |
SEER2 |
18.9 |
EER2 |
9.7 |
HSPF2-4 |
8.7 |
HSPF2-5 |
6.9 |
COOLING CAPACITY (BTU) |
24,000 |
HEATING CAPACITY (BTU) |
25,000 |
VOLTAGE / PHASE / CYCLE |
208/230 V / 1 / 60 Hz |
MAX FUSE / BREAKER (A) |
20 |
MIN CIRCUIT AMPACITY (A) |
19 |
COLOR |
White |
ZONE CAPACITY |
1 |
REFRIGERANT TYPE |
R-454B |
REFRIGERANT VOLUME (OZ) |
50.44 |
DECIBEL RATING (DBA) |
61 |
INVERTER |
Yes |
LINE SET INCLUDED |
Yes |
LINE SET LENGTH |
11.5 ft |
MAX LINE SET LENGTH (FT) |
75 ft |
LIQUID LINE SIZE |
3/8 in |
SUCTION LINE SIZE |
5/8 in |
COMPRESSOR MOTOR TYPE |
Rotary |
CONDENSER FAN MOTOR TYPE |
DC |
CONDENSER FAN MOTOR RPM |
830/700/550 |
METERING DEVICE |
EEV |
UL / CSA / ETL LISTED |
Yes / Yes / Yes |
ENERGY STAR CERTIFIED |
No |
AHRI CERTIFIED |
Yes |
BASE WARRANTY |
3 Year Parts, 5 Year Compressor |
BASE PARTS WARRANTY |
3 Year Parts |
BASE COMPRESSOR WARRANTY |
5 Year Compressor |
CONTAINS ELECTRONICS |
Yes |
CONTAINS CHEMICALS |
Yes |
CONTAINS COMPRESSED GAS |
Yes |
PROPOSITION 65 WARNING |
Yes |
CONDENSER NET DIMENSIONS (D X H X W) |
13.46 x 26.5 x 35.04 in |
CONDENSER NET WEIGHT |
95.9 lb |
CONDENSER GROSS DIMENSIONS (D X H X W) |
15.67 x 29.13 x 39.17 in |
CONDENSER GROSS WEIGHT |
117.73 lb |
AIR HANDLER CFM |
729.9 / 547.4 / 400.2 / 329.6 |
AIR HANDLER TONNAGE |
2 |
AIR HANDLER VOLTAGE |
208/230 V |
AIR HANDLER MAX FUSE / BREAKER (A) |
15 |
AIR HANDLER MIN CIRCUIT AMPACITY (A) |
3 |
MAX COVERAGE AREA |
1,050 sq. ft. |
AIR HANDLER ZONE CAPACITY |
1 |
AIR HANDLER REFRIGERANT TYPE |
R-454B |
AIR HANDLER DECIBEL RATING LOW (DBA) |
21.5 |
AIR HANDLER DECIBEL RATING HIGH (DBA) |
51.5 |
OSCILLATION |
Yes |
BLOWER MOTOR TYPE |
DC |
BLOWER MOTOR RPM |
1100/940/780 |
FILTER TYPE |
Reusable |
ADJUSTABLE THERMOSTAT |
Yes |
FAN ONLY OPTION |
Yes |
SLEEP MODE |
Yes |
AUTO COOL |
Yes |
WIFI COMPATIBILITY |
Yes |
APP COMPATIBILITY |
Yes |
WORKS WITH IOS |
Yes |
WORKS WITH ANDROID |
Yes |
REMOTE CONTROL INCLUDED |
Yes |
AIR HANDLER WARRANTY |
3 Year Parts |
REMOTE WARRANTY |
3 Year |
HAS BATTERIES |
Yes |
AIR HANDLER NET DIMENSIONS (D X H X W) |
9.21 x 13.27 x 42.6 in |
AIR HANDLER NET WEIGHT |
35.49 lb |
AIR HANDLER GROSS DIMENSIONS (D X H X W) |
17.67 x 14.09 x 46.73 in |
AIR HANDLER GROSS WEIGHT |
49.6 lb |
